Rosenbauer Trucks

IDEA: Design Award Winners, 2008

199 of 204next slideprevious slide

DATA AND IMAGES PROVIDED BY IDSA

Rosenbauer Panther

Gold
Transportation
Client: Rosenbauer International (Austria)
Design: Spirit Design (Austria)

The Rosenbauer Panther is a high-performance fire engine for airports. With eight direct-drive wheels, an operating weight of 40 tons, a capacity of 3,830 gallons (14,500 liters) of fire extinguishing agents and a maximum speed of 87 mph (140 km/h), this new 8x8 model is the highest quality airport fire-fighting vehicle availableRosenbauer Panther 4X4 Aircraft Rescue & Firefighting (ARFF) fire truck
They are usually forgotten, as they tend to see a lot less action than non-airport bound firefighters, but boy, do they have cool equipment to play with! Airport fire departments have some very tight performance parameters, basically, because when a huge piece of aluminium, titanium, passengers and fuel crashes and ignites on or near a runway, every second counts. That’s the reason this 40-ton baby accelerates from 0 to 80 Km/h (50mph) in around 25 seconds. In proportion to weight, this is faster than a 1997 McLaren F1, which hits 100 Km/h (60mph) in 3.3 seconds! And this is what it looks like:

The Rosenbauer Panther 8×8 MA5 airport and rescue firefighting vehicle. Sporting a 1000 hp engine (yes, that is not a typo), it carries 12.5 tons of water, 1.5 tons of foam liquid, and up to 1 ton of NP powder. Full specs here. Up to three monitors (two mounted at the front, one top) give it a range from 25 meters up to 85 meters, all controlled from the cabin with joysticks and cameras. At 11 bars of pressure, the top monitor can empty the water tank in two minutes. The cabin controls look like something out of Star Wars:

Note the complex MFD control system for the hydraulics – so much for turning a wheel and having water come out a hose, right? While I did part-time work at Southend Airport, I was able to ride and operate a much smaller, much simpler, but equally fun Carmichael truck. Will post a pic when I find it and scan it (film rolls back then, the only thing digital in cameras was your finger).Seen @ Mumbai Port, high speed Rosenbauer Panther fire trucks waiting to be shipped to Delhi Airport.






Rosenbauer FL Panther 6x6 Truck 816 from The Port of Portland Airport Fire Rescue parked on C-11 at PDX

Airport 11 - 2004 Rosenbauer P19H with Snozzle - 1,500gal/200foam/500lb Dry Chemical Crash 11 is the newest rig in the ARFF fleet. It is one of only a few Rosenbauer crash trucks in service with the USAF.
Airport 11 - 2004 Rosenbauer P19H with Snozzle - 1,500gal/200foam/500lb Dry Chemical Crash 11 has a pump that delivers 1000gpm through it's Snozzle brand elevating waterway. The boom is also equipped with a video camera and thermal imaging camera. A bumper turret also assists with fire suppression.
